Farber 960 BX Hand Held Slit Lamp
The Farber portable hand held slit lamp with case allows the optometrist to examine the eye in detail for signs of infection. This is an important tool for accurate diagnosis of anterior eye problems such as conjunctivitis, dry eye, and blepharitis. This portable slit lamp utilizes a high luminance white LED light source, coupled with a lightweight, compact design, to give the freedom of using a slit lamp in the palm of the hand. It is small & light weight and weighs only 1.5 lbs. with its battery. It fits easily and comfortably in the hand. Its ergonomic, portable design and convenient carrying case makes it an ideal instrument for non-ambulatory patients, nursing home visits & veterinary work.
Total magnification:10X eyepiece 16X eyepeice1X objective 10X 16XDioptor compensation: ±5DDiameter of light: 0.1, 1, 3,10mmPupil distance: 45-70mmWorking distance: 78mmSlit width: 0mm~ 10mm continuously adjustable Slit hight0.2, 0.3, 5,10mmFilter: Hear absorption, Red free, Cobalt blueIllumination rotator angle: horizontal ±30°Illumination: White LED Power supply: 7.4V680MAH (Lithium battery)Working time: 2hours with fully recharged Net Weight0.75kgGrass Weight1.8kgVolume: 180mmX155mmX370mm
New IBEX 2 Step LED Slit Lamp
A Leap Forward in Slit Lamp Engineering
Born from unrestrained engineering and smart innovations, iBEX Slit Lamps have upped the ante on what a doctor should expect in slit lamp microscopy. Simply stated, where tungsten and halogen illumination slit lamps restrict observation quality, iBEX’s fine-tuned LED Illumination system actually increases visualization of eye tissue while delivering less output temperature to the patient’s eye.Even within prolonged high intensity observation, the iBEX remains exceptionally stable and low temperature. Just turn it up.
iBEX combines optimal color temperature (K) and color rendering index (CRI) with high performance optics. This creates a very specific color hue that delivers brightness and contrast to distinguish one tissue structure from another. It’s a combination that can only be achieved by highly specialized LED illumination.
IBEX 5-Step LED Slit Lamp
A Milestone in Slit Lamp Engineering Building a slit lamp that delivers new levels of tissue observation, coupled with high magnifications and unprecedented field of views, required new solutions and ultimately an advanced optical system.
After intensive design and engineering work, milestones were ultimately achieved and the success laid the foundation for the iBEX 5-Step – and a leap forward in slit lamp observation.
Today the iBEX 5-step provides the optical properties required to integrate the slit lamp’s wide-field lens system, pure light transmission and high magnifications. The result: stunning clarity, six magnifications at your fingertips and a field of view second to none.
Pushing ahead, iBEX’s 4300k color temperature LED delivers new and high-contrast, homogeneous white light for substantial gains in slit lamp observation.
The following gains were once difficult, if not impossible to carry out with conventional illumination: increased tissue fluorescence, enhanced tissue differentiation, increased depth of field, shadow reduction, less temperature. Plus illumination intensity second to none. It’s a leap beyond conventional tungsten and halogen illumination.
Built around the physician, the iBEX design and engineering teams have gone to great lengths to ensure that the mechanical system exemplifies attention to detail and encompasses a host of outstanding features.
Performance, safety and endurance are standard with every iBEX slit lamp.
LEGEND Series Slit Lamp Model YZ-5F
Slit Lamp with precisely engineered German-imported Schott optics reduce optical distortion, and increase clarity and depth of focus. Single joy-stick design easily controls both horizontal focus and vertical elevation.Tilt mechanism for ease of angled examination.
Eyepiece diopter adjustment to 10x (±8D) and 16x (±10D). Contains magnification at 10x (f18 mm), 16x (f14.5 mm), 16x (f11.25 mm), and 25.6x (f9 mm). Halogen light source for acute illumination.
All optical lenses are moisture-proof, mildew-proof, and anti-reflective.
Retrofit your existing BM 900 Haag-Streit Slit Lamp to
LED,and Shatter the Status Quo
Introducing the LED Retrofit Kit for the BM 900 and the BQ 900. Try the new Haag-Streit LED slit lamp and you'll:
-
Observe eye structures in breathtaking detail
-
More power in the short wave lengths improves fluorescence and anterior chamber illumination
-
Cooler operation is more comfortable for doctor and patient
-
Retrofit kits include LED light housing, brand new table top with power supply, rheostat controls and more
-
Retrofit kit for BM900 includes 2nd LED for Imaging background illumination
-
Target lifetime of LED Illumination Unit is 35,000 hours
Retrofit your existing BQ 900 Haag-Streit Slit Lamp to
LED,and Shatter the Status Quo
Introducing the LED Retrofit Kit for the BM 900 and the BQ 900. Try the new Haag-Streit LED slit lamp and you'll:
-
Observe eye structures in breathtaking detail
-
More power in the short wave lengths improves fluorescence and anterior chamber illumination
-
Cooler operation is more comfortable for doctor and patient
-
Retrofit kits include LED light housing, brand new table top with power supply, rheostat controls and more
-
Retrofit kit for BQ 900 includes 2nd LED for Imaging background illumination
-
Target lifetime of LED Illumination Unit is 35,000 hours
Topcon SL-3G Slit Lamp
The new SL-3G Slit Lamp combines classic versatility with a smooth and effortless mechanism. Its stereoscopic converging microscope and carefully crafted optics provides the practitioner with excellent image clarity and sharpness. This reduces fatigue while providing a clearer field of view. Magnifications can easily and smoothly be changed between 1X to 1.6X using the conveniently located lever.
-
Bright, even illumination and optimum color rendition with powerful halogen bulb
-
Smooth, effortless control with Topcon's omni-directional joystick
-
Slit beam inclination up to 20 degrees for added versatility
-
Continuous adjustment of slit aperture
-
Four built-in filters: cobalt blue, red-free, 13% neutral density and heat absorbing
-
Precise angular measurement scale simplifies the fitting of astigmatic contact lenses
-
Available with a variety of optional accessories
Topcon SL-D4 Slit Lamp
-
Five convenient magnification ratios of 6X, 10X, 16X, 25X and 40X
-
Optional DC-3 or DC-4 digital camera for high resolution color image & video clips.
-
40X magnification useful in corneal endothelium observation
-
Excellent imaging of the anterior and posterior structures of the eye
-
Optimized clarity, color resolution and depth-of-field
-
Compact and easy to use
-
Available in table mount or unit configuration
